MM OM1 OM2 OM3 OM4 DX 3.0mm G652D Fiber Optic Patch Cord Cable

SC/UPC-SC/UPC MM OM1 OM2 OM3 OM4 DX 3.0mm G652D Fiber Optic Patch Cord Cable

Model NO. SC/UPC-SC/UPC MM

Material:PVC/LSZH
Mode:SM/MM/OM3/OM4
Connector:FC,SC,ST,LC,MU,MTRJ,E-2000 and other
Length:1m,2m,3m,5m,10m,15m...
Application:WAN LAN FTTX CATV
Ferrule:APC PC UPC
Color:Yellow/Green/Orange etc
Fiber Type:G657A/G652D/customized

Quantity

FC/ST Fiber Optic Connector
Conector	PC(SM)	UPC(SM)	APC(SM)	PC(MM)
Return Loss(dB)	≥45	≥50	≥60	≥35
Insertion Loss(dB)	≤0.2(Typical)≤0.3(MAX)
Repeatability(dB)	≤0.1
Durability(times)	≥1000
Operating Temperature(℃)	-100~+80
Tensile Strength(N)	≥90(φ3）≥70（φ2)

SC Fiber Optic Connector
Conector	PC(SM)	UPC(SM)	APC(SM)	PC(MM)
Return Loss(dB)	≥45	≥50	≥60	≥35
Insertion Loss(dB)	≤0.2(Typical)≤0.3(MAX)
Repeatability(dB)	≤0.1
Durability(times)	≥500
Operating Temperature(℃)	-25~+70
Tensile Strength(N)	≥90(φ3）≥70（φ2)

LC Fiber Optic Connector
Conector	PC(SM)	UPC(SM)	PC(MM)
Return Loss(dB)	≥45	≥50	≥35
Insertion Loss(dB)	≤0.2(Typical)≤0.3(MAX)
Repeatability(dB)	≤0.1
Durability(times)	≥500
Operating Temperature(℃)	-25~+70
Tensile Strength(N)	≥90(φ3）≥70（φ2)
