2LC/UPC-2LC/UPC G657A G652D FTTH Drop Cable Outdoor Fiber Optic Cable Patch Cord
2LCUPC-2LCUPC
It is a fiber optic cable capped at either end with connectors that allow it to be rapidly and conveniently connected to CATV, an optical switch, or other telecommunication equipment. This figure-eight drop cable is made of four fiber cores, one Φ1.0mm steel wire, two Φ0.5mm FRP rods and LSZH outer jacket. Fiber core type is available with different type upon different application demands. Two kinds of reinforced will provide superior mechanical load during outdoor fttx application.
Quantity
Product specification
Project | technical parameter |
Optical cable model | GJXH 1-4 core |
Product specification | 2.0×3.0 |
Fiber color | Blue, orange |
Optical fiber specification(SM) | 9/125 (G.657A2) |
Outer sheath color | White, Black (According to the specific requirements of customers) |
Outer sheath material | LSZH |
Cable diametermm | 2.0(±0.1)*3.0(±0.1) |
Cable weightKg/km | 8.0 |
Minimum bending radiusmm | 15(static state) 30(dynamic) |
Short term tensionN | 100 |
Long term tensionN | 60 |
Short term flattening force N/100mm | 1000 |
Long term flattening force N/100mm | 500 |
Working temperature ℃ | -10~+50 |
Note: the product complies with EU ROHS directive.
