1*2 Cassette Optical Splitter FTTH Fiber optic PLC splitter 1x2 FC APC Connector
OP-PLC-CKFA2
Product name :Plc Splitter ABS Box FC Connectors Cassette Type
Connector Type :FC APC
Size :120*100*25mm
Weight :0.15kg
Fiber Type :G657A1
Wavelength :1260nm-1650nm
Insertion Loss :≤3.6dB
Connector count :2
Material :ABS
Application :FTTH, FTTB, FTTO, FTTX
Connector Type :FC APC
Size :120*100*25mm
Weight :0.15kg
Fiber Type :G657A1
Wavelength :1260nm-1650nm
Insertion Loss :≤3.6dB
Connector count :2
Material :ABS
Application :FTTH, FTTB, FTTO, FTTX
Quantity
Overview:
An optical splitter is a passive device that does not require external energy or power supply, as long as there is an input optical signal. A fiber splitter is a fiber optic passive device that divides and combines optical signalsFeatures:
Loss is not sensitive to the wavelength of transmitted light, meeting the transmission needs of different wavelengths. Low insertion loss, uniformity, good directionality, and excellent optical performance
Advantages:
All fiber construction, stable environment, low polarization related loss, low back reflection, compact structure, and small volume
All fiber construction, stable environment, low polarization related loss, low back reflection, compact structure, and small volume
Application:
The optical splitter can be used for network generic cabling, fiber to the home system, cable television network, Passive optical network, fiber local area network, etc. The equipment is fast to install and easy to operate, and can be installed in about 30 seconds
